2. Enter the ADDRESS in the "Address" box.
3. Enter the VALUE in the "value" box.
4. Click the "Add" button to confirm the change.
The POKE will be added to the POKE list window with a tick next to it, to indicate the POKE is active.
You can disable a POKE by clicking the tick next to the POKE you want disabled.
Repeat steps 2-4 as required, and click the close window X when done.
Once you have the Multiface 128 ROM, rename it to mf128.rom (if it isn't already called that. Chances are it will be,
as this is pretty much the standard filename).
You don't actually have to rename it, as R80 lets you choose the ROM, but it saves a lot of
hassle (plus it's handy if you want to use another Multiface capable emulator as well as/instead of R80)
Copy the mf128.rom file to the same directory as the main r80 program, start R80.
1. Press F2, and highlight the model of Speccy you want to emulate.
2. Ensure the Multiface is active for this model, by pressing SPACE. You should switch to the screen below.
3. Ensure "Multiface" is set to "on". Ignore the "Multiface ROM" option below that. That's for if you didn't rename it.
We already renamed it, so we're happy.
4. Once your screen's Multiface section matches the image above, press ESC to return to the first screen (the hardware selection one).
5. Press ESC again to return to the emulator.
6. To activate the Multiface, just hit F11 to get this screen:
7. Highlight "Multiface 128", and press ENTER. The Multiface will launch.
The good news is that you won't have to go through all that again. Erm, so long as you don't do anything daft
like changing the .ini file, or the like. You only need do steps 6 and 7. Yay!
1. From the "Monitor" menu, select "POKE Memory" (as above). You should see something like:
2. Enter the ADDRESS in the "Address" box
3. Enter the VALUE in the "Value" box
4. Click POKE
Repeat steps 2-4 as required, and close the box to return to the emulator.
Using the Multiface
Copy the Multiface 128 ROM (mf128.rom) and the +3 version if required (called mf3.rom) to the same directory where you have SpecEmu installed.
The Multiface 128 should activate when you press the PAUSE/BREAK key.
1. From the "View" menu, select POKEs and Tips (as above). You should now see something like:
2. Enter the ADDRESS in the "Address" box
3. Enter the VALUE in the "Value" box
4. Click POKE
Repeat steps 2-4 as required, and close the box to return to the emulator.
Using the Multiface emulation
1. Ensure mf128.rom is in the same directory as the main SPIN program BEFORE starting the emulator.
2. From the "View" menu, select Options (as above). You should now see something like:
3. Under the "Hardware" menu, select the model of Spectrum you want to emulate (48/128),
and in the pull down menu below that, select "Multiface 128" (as shown above)
4. Close the box to return to the emulator.
1. Press F3 to enter the Monitor
2. Type M ADDRESS (replacing ADDRESS with the ADDRESS. Eg M 54321. There MUST be a space between the M and the number)
3. Press ENTER
4. Type P VALUE (replacing VALUE with the VALUE. Eg P 183. There MUST be a space between the P and the number)
This emulator doesn't have the ability to POKE via a GUI. However, it does come preloaded with the Multiface 128 ROM in place
allowing you to enter POKEs the way you would have to on a normal Speccy - with a Multiface.
Because of this, the intructions are split in two. This section will tell you how to activate the Multiface within the
emulator. You should then refer to the section detailing how to use the Multiface. That section can be found HERE.
Press F9, or select "Hardware" from the "Settings menu" (as shown above)
This should open a window as above. Ensure the box marked "Multiface 128 is checked, as above.
With this checked, you can activate the Multiface 128 at any time by pressing F5.
Pease refer to the section on Using the Multiface 128 for further details.
This emulator doesn't have the ability to POKE via a GUI. However, it is compatible with the Multiface 128 ROM MF128.ROM file.
Unlike Z80 and WinZ80, it doesn't come with the ROM as part of the standard installation (Boo!). Unlike those two, it's free (Yay!)
As I'm unsure of the situation with the Multiface ROM (several downloadable emulators come with it), I'm unwilling to say where
to find it. However, those nice peeps at Yahoo and Google will help you find it. If it takes you any longer than 5 minutes to find it,
you're obviously not doing something right! :-)
Anyway, once you have the MF128.ROM file, copy it to the directory where you have X128 installed. If you've done it all correctly,
the Multiface 128 should activate when you press F2. You should then refer to the section on Using the Multiface 128 for further details.
The version I downloaded had mf128.rom and mfplus3.rom (Multiface +3) included, but I'm not sure if this was a mistake or not. If the version you have doesn't, then you'll have to find it yourself.
It should be in the same directory where you have YASE installed.
Note that you will require mfplus3.rom if you want to use the Multiface while emulating a +3.
Also, Multiface will only work in the "Spectrum" models (so don't use Dadaktik, Pentagon or Scorpion)
The Multiface 128 should activate when you press F6.
WinZ80 is essentially just a Windows version of Z80, so the instructions are basically
the same - the menus just look different.
This emulator doesn't have the ability to POKE via a GUI. However, it does come preloaded with the Multiface 128 ROM in place
allowing you to enter POKEs the way you would have to on a normal Speccy - with a Multiface.
Because of this, the intructions are split in two. This section will tell you how to activate the Multiface within the
emulator. You should then refer to the section detailing how to use the Multiface. That section can be found HERE.
Press F9 to get to the Select hardware menu (as shown above).
Press M so that the section marked "[M]ultiface 128:" toggles to ON.
Press ESC to return to the emulator (assuming you don't want to switch to a different model of Spectrum)
You can activate the Multiface 128 at any time by pressing F5.
Pease refer to the section on Using the Multiface 128 for further details.
If you don't like the Multiface interface, there is another way of doing it.
1. Press F9 to get to the Select Hardware screen.
2. Select the option with SamRam included and press CTRL+ENTER to select without reset.
3. Press D.
4. You should drop into a MONS-type asssembler.
5. Press M to enter the address of the POKE (in HEX). Press ENTER
6. Press B. Enter the VALUE of the POKE in HEX. Press ENTER.
5. Type the VALUE (a box will appear). Press ENTER to confirm the change
(Note you will have to delete the # if the VALUE of your POKE is in decimal and not zero)
Repeat steps 3-5 as required, and press ESC to return to the emulator.
Enter as many ADDRESSES and VALUES as you require, and click the close window X when done.
Back to the top Using the MULTIFACE 128
Several emulators, including R80, X128, WinZ80, and Z80 allow you to use the Multiface 128. The details on how to activate it are listed
for each individual emulator. This section tells you how to use it once you have it installed.
When Multiface 128 is activated, you should see this screen. If you don't you probably have a version
of the MF128 rom which has the add-on program Genie installed. Click HERE for the instructions on using that.
If you didn't want the Multiface (erm, why are you reading this, then?), press "r" to exit.
Otherwise, follow these steps which will guide you to entering a POKE using the Multiface 128.
1. Press T for tool. You will see it displays an example POKE setting as above.
2. Press SPACE to clear the ADDRESS box to allow you to enter your own (as above).
Upon entering the ADDRESS part of the POKE, the screen will automatically change to show
the current VALUE of the ADDRESS you just entered.
4. Enter the VALUE part of the POKE in the "Poke:" box, and press ENTER
You should see the VALUE of the ADDRESS you typed in has now been altered to the VALUE you keyed in.
If you realise you've made a mistake with this VALUE, repeat step 4.
If you require to enter any more POKEs, go back to step 2.
Otherwise press q to return to the first page, and r to leave the multiface.
4. Enter the ADDRESS part of the POKE. As soon as you enter the last digit of the POKE, it should
change to show you the current VALUE of that ADDRESS (as below)
5. Enter the VALUE part of the POKE. If the VALUE is less than 3 digits, press RETURN to confirm the
change. If it is a 3 digit number, the change will be confirmed automatically, and the screen
will change to show the new VALUE of the memory ADDRESS (as above)
Press SPACE to return to a screen similar to the one you should see at Step 3 of above.
If you need to enter any more POKEs, go back to step 3. Otherwise, press SPACE again to return to the start.
Press R to leave the Genie multiface utility, and go back to the game.
